APC Easy-UPS BV500I-GR - 4x Schuko socket, 500VA
€84.62
€71.11
APC Easy-UPS BV500I-GR - 4x Schuko socket, 500VA
Availability:
In stock
Only 32 left
SKU
BV500I-GR
- Compact size acommodates installation in a variety of environments
- AVR corrects voltage variations to provide reliable power
- LED display provides easy-to-read status of unit and utility power conditions
- Cold start function allows you to reboot the UPS even when utility power is unavailable
| Output power capacity | 0.5 kVA |
|---|---|
| Product colour | Black |
| Output power | 300 W |
| Form factor | Compact |
| SKU | BV500I-GR |
| EAN | 0731304338284 |
| Manufacturer | APC |
| Availability | In Stock |
| Product Manuals (HTML) |
View Manual |
| PDF URLs |
View PDF View PDF |
Write Your Own Review
Security through emergency power
An APC Easy-UPS has a built-in battery that ensures that all connected devices, such as a NAS, router, modem and media box, continue to work if the power goes out. This prevents downtime, damage to equipment, and loss of data.
Safety and convenience
In addition, this safe APC UPS protects valuable equipment against peak voltage caused, for example, by lightning strikes. Because the APC Easy-UPS BV500I-GR can also be mounted on the wall and is equipped with 4 rotated sockets (45°), this APC emergency power supply is also a suitable UPS for the meter cupboard.
Expected battery life
Load in Watts, battery life in Minutes:
10W = 100 Min.
40W = 40 Min.
80W = 18 Min.
120W = 5 Min.
180W = 3 Min.
240W = 0.5 Min.
Extends battery life
The AVR function extends both the expected battery life and the expected runtime by correcting both low and high voltages without discharging the battery.
Warranty extension
The factory warranty of the BV500I-GR is 2 years and you can upgrade to 5 years with the APC service pack (WBEXTWAR3YR-SP-01A).
An APC Easy-UPS has a built-in battery that ensures that all connected devices, such as a NAS, router, modem and media box, continue to work if the power goes out. This prevents downtime, damage to equipment, and loss of data.
Safety and convenience
In addition, this safe APC UPS protects valuable equipment against peak voltage caused, for example, by lightning strikes. Because the APC Easy-UPS BV500I-GR can also be mounted on the wall and is equipped with 4 rotated sockets (45°), this APC emergency power supply is also a suitable UPS for the meter cupboard.
Expected battery life
Load in Watts, battery life in Minutes:
10W = 100 Min.
40W = 40 Min.
80W = 18 Min.
120W = 5 Min.
180W = 3 Min.
240W = 0.5 Min.
Extends battery life
The AVR function extends both the expected battery life and the expected runtime by correcting both low and high voltages without discharging the battery.
Warranty extension
The factory warranty of the BV500I-GR is 2 years and you can upgrade to 5 years with the APC service pack (WBEXTWAR3YR-SP-01A).
| Power | |
|---|---|
| Output power | 300 W |
| Input operation voltage (min) | 170 V |
| Input operation voltage (max) | 280 V |
| Surge energy rating | 156 J |
| Output power capacity | 0.5 kVA |
| Ports & interfaces | |
| Cable length | 1.52 m |
| AC outlets quantity | 4 AC outlet(s) |
| AC outlet types | Type F |
| Performance | |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| Number of output phases | 1 |
| Number of input phases | 1 |
| LED indicators | Yes |
| Surge protection | Yes |
| Noise level | 40 dB |
| Audible alarm(s) | Yes |
| Transfer time (Line Mode to Battery Mode) | 6 ms |
| Features | |
| Output frequency | 50/60 Hz |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| Number of output phases | 1 |
| Number of input phases | 1 |
| Output power | 300 W |
| Input operation voltage (min) | 170 V |
| Input operation voltage (max) | 280 V |
| Surge energy rating | 156 J |
| Surge protection | Yes |
| Noise level | 40 dB |
| Audible alarm(s) | Yes |
| Output power capacity | 0.5 kVA |
| Transfer time (Line Mode to Battery Mode) | 6 ms |
| Input frequency | 50/60 Hz |
| Battery | |
| Battery voltage | 12 V |
| Battery capacity | 4.5 Ah |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 8 h |
| Cold start | Yes |
| Design | |
| Form factor | Compact |
| LED indicators | Yes |
| Product colour | Black |
| Certification | CE REACH |
| Cable length | 1.52 m |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating altitude | 0 - 1968.3 m |
| Technical details | |
| Output frequency | 50/60 Hz |
| Harmonized System (HS) code | 85078000 |
| Compliance certificates | RoHS |
| Certificates | |
| Certification | CE REACH |
| Compliance certificates | RoHS |
| Weight & dimensions | |
| Package width | 373 mm |
| Package depth | 143 mm |
| Package height | 237 mm |
| Weight | 3.9 kg |
| Width | 160 mm |
| Package weight | 4.2 kg |
| Height | 92 mm |
| Depth | 305 mm |
| Packaging data | |
| Package width | 373 mm |
| Package depth | 143 mm |
| Package height | 237 mm |
| Package weight | 4.2 kg |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Nominal output voltage | 230 V |
