Digitus CAT 7 S/FTP data cable - underground installation cable, 500 m, simplex, PE
€717.53
€602.97
DIGITUS CAT 7 S-FTP PiMF installation cable, raw 500m, drum, AWG 23/1, 1200 MHz, PE, sx, bl
Availability:
In stock
Only 5 left
SKU
DK-1741-VH-5-OD
- Physical properties:
- Conductor: Bare copper wire, AWG 23/1
- Insulation: SFS-PE (foamed polyethylene jacket)
- Total number of insulated conductors: 8, twisted into 4 pairs
- Color code: Blue-white, orange-white, green-white, brown-white
- Shielding of the individual pairs: Aluminum-laminated polyester film, covers 100%
- Overall shielding: copper braiding
- Outer sheath: PE (polyethylene); UV-resistant
- Outer sheath thickness (nominal): 0.50 mm nominal
- Outer casing color: Black (RAL 9005)
- Mechanical properties:
- Strain relief: 150N max.
- Dynamic bending radius: 8x AD mm min.
- Static bending radius: 4x AD mm min.
- Transport and storage temperature range: -20 °C to +60 °C
- Operating temperature range: -50 °C to +60 °C
- Installation temperature range: 0 °C to +60 °C
- Outer diameter simplex (nominal): 8.5 mm (Eca)
- Weight (kg/km): 66.5 kg/km
- Electrical properties:
- Impedance: 100±5 Ohm @ 4-100 MHz; 100±25 Ohm @ 100-1200 MHz
- Capacitance: 45 pF/m nominal @ 1 KHz
- Capacitance unbalance (pair-earth): 1.6 pF/m max. @ 1 KHz
- Insulation resistance: 5 GOhm x km min.
- DC resistance: 95 Ohm/km max. (2% max. unbalanced resistance)
- Loop resistance: 190 Ohm/km max. (2% max. unbalanced resistance)
- Operating voltage: 72 Vdc max.
- Coupling attenuation: CA-Type 1b
- Phase delay: 450 nS/100 m max.
- Time delay: 10 nS/100 m max.
- Separation class: "d" according to EN 50174-2
- NVP: 79%
| Cable length | 500 m |
|---|---|
| Connector 2 | No |
| Connector 1 | No |
| Cable shielding | S/FTP (S-STP) |
| SKU | DK-1741-VH-5-OD |
| EAN | 4016032431084 |
| Manufacturer | Digitus |
| Availability | In Stock |
Write Your Own Review
Future-oriented standards and high-end quality for your network.
- 10GBit Ethernet
- 1200 MHz transmission frequency
- Permanent Link certified
- PoE Power over Ethernet support
- PE outer sheath, BauPVO class Eca inner sheath
The Digitus® Professional Cat.7 S/FTP underground cable is characterized by the following cable structure 4x2x AWG23/1 and achieves a transmission frequency of up to 1200 MHz. The cable has a PE outer sheath and a halogen-free inner sheath and conforms to the IEC 60332-1, FRNC-B, LSZH-1 and BauPVO Euroclass Eca standards. The cable is suitable for installations in dry or damp rooms, outdoors or in the ground. Conforms to the standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-4-1.
- 10GBit Ethernet
- 1200 MHz transmission frequency
- Permanent Link certified
- PoE Power over Ethernet support
- PE outer sheath, BauPVO class Eca inner sheath
The Digitus® Professional Cat.7 S/FTP underground cable is characterized by the following cable structure 4x2x AWG23/1 and achieves a transmission frequency of up to 1200 MHz. The cable has a PE outer sheath and a halogen-free inner sheath and conforms to the IEC 60332-1, FRNC-B, LSZH-1 and BauPVO Euroclass Eca standards. The cable is suitable for installations in dry or damp rooms, outdoors or in the ground. Conforms to the standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-4-1.
| Features | |
|---|---|
| Product colour | Black |
| Country of origin | China |
| Conductor material | Copper |
| Frequency | 1200 MHz |
| AWG wire size | 23/1 |
| Plug and Play | Yes |
| Cable standard | Cat7 |
| Cable class | F |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | No |
| Connector 2 | No |
| Cabling technology | 10GBase-T |
| Networking standards | IEEE 802.3, IEEE 802.5 |
| Jacket material | Polyethylene (PE) |
| Conductor type | Solid |
| Cable length | 500 m |
| Ethernet interface type | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power over Ethernet (PoE) | Yes |
| Cable shape | Round |
| Connector 2 gender | No |
| Connector 1 gender | No |
| Power over Ethernet (PoE) type supported | PoE+, PoE++ (4PPoE) |
| Certification | CPR class Eca |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | -20 - 60 °C |
| Certificates | |
| Certification | CPR class Eca |
| Weight & dimensions | |
| Weight | 65.5 kg |
| Packaging content | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package volume | 72600 cm³ |
| Package width | 550 mm |
| Package depth | 240 mm |
| Package weight | 32 kg |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Product colour | Black |
| Plug and Play | Yes |
| Cable standard | Cat7 |
| Cable class | F |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | No |
| Connector 2 | No |
| Cabling technology | 10GBase-T |
| Networking standards | IEEE 802.3, IEEE 802.5 |
| Jacket material | Polyethylene (PE) |
| Conductor type | Solid |
| Cable length | 500 m |
| Country of origin | China |
| Logistics data | |
| UK Trade Tariff code | 85444920 |
