Digitus CAT 7A S/FTP installation cable, 500 meters, simplex, B2ca-s1a,d0,a1, GHMT PVP certified
€1,371.87
€1,152.83
CAT 7A S-FTP installation cable, 1500 MHz B2ca (EN 50575), AWG 22/1, 500 m drum, Sx, yellow
Availability:
In stock
Only 2 left
SKU
DK-1745-A-VH-5
- Physical properties:
- Conductor: Bare copper wire, AWG 22/1
- Insulation: SFS-PE (foamed polyethylene jacket)
- Total number of insulated conductors: 8, twisted into 4 pairs
- Color code: Blue-white, orange-white, green-white, brown-white
- Shielding of the individual pairs: aluminum-laminated polyester film, covers 100%
- Overall shielding: copper braiding
- Outer sheath: B2ca-s1a,d0,a1 according to EN 50575; LSZH
- Outer sheath thickness (nominal): 0.50 mm (Eca); 0.52 mm (Dca); 0.60 mm (Cca); 0.60 (B2ca)
- Mechanical properties:
- Strain relief: 150N max.
- Dynamic bending radius: 8x AD mm min.
- Static bending radius: 4x AD mm min.
- Transport and storage temperature range: -20 °C to +60 °C
- Operating temperature range: -20 °C to +50 °C
- Installation temperature range: 0 °C to +50 °C
- Outer diameter simplex (nominal): 7.0 mm (Eca); 7.2 mm (Dca); 7.5 mm (Cca); 7.5 mm (B2ca)
- Weight (kg/km): 49.5 kg (Eca); 51 kg (Dca), 53 kg (Cca); 53 kg (B2ca)
- RAL 1016
- Electrical properties:
- Impedance: 100±15 Ohm @ 4 - 1000 MHz; 100±25 OHM @ 100-600 MHz
- Capacitance: 45 pF/m nominal @ 1 KHz
- Capacitance unbalance (pair-earth): 1.6 pF/m max. @ 1 KHz
- Insulation resistance: 5 GOhm x km min.
- DC resistance: 95 Ohm/km max. (2% max. unbalanced resistance)
- Loop resistance: 190 Ohm/km max. (2% max. unbalanced resistance)
- Operating voltage: 72 Vdc max.
- Coupling attenuation: CA-Type 1b
- Phase delay: 450 nS/100 m max.
- Time delay: 10 nS/100 m max.
- Separation class: "d" according to EN 50174-2
- NVP: 79%
- Flame spread: EN 60332-1-2 (LSOH-PVC)
- Halogen-free, corrosiveness: EN 60754-1/2 (LSOH)
- Smoke density: EN 61034-2
| Cable length | 500 m |
|---|---|
| Connector 2 | No |
| Connector 1 | No |
| Cable shielding | S/FTP (S-STP) |
| SKU | DK-1745-A-VH-5 |
| EAN | 4016032435921 |
| Manufacturer | Digitus |
| Availability | In Stock |
Write Your Own Review
Future-oriented standards and high-end quality for your network.
- 10GBit Ethernet
- 1500 MHz transmission frequency
- GHMT PVP certified
- PoE, PoE+, Power over Ethernet support
- BauPVO class B2ca-s1a,d0,a1
The Digitus® CAT 7 S/FTP installation cable is designed for use in structured data center & building cabling in accordance with ISO/IEC 11801, DIN EN 50173, IEC 61156-7, EN 50288-9-1. Ideally suited for the transmission of analog and digital, data, audio and video signal transmission, 10 Gbit Ethernet, POE and POE+. The shield structure consists of individually shielded pairs with a tinned copper braid, which ensures excellent shielding and electrical values.
- 10GBit Ethernet
- 1500 MHz transmission frequency
- GHMT PVP certified
- PoE, PoE+, Power over Ethernet support
- BauPVO class B2ca-s1a,d0,a1
The Digitus® CAT 7 S/FTP installation cable is designed for use in structured data center & building cabling in accordance with ISO/IEC 11801, DIN EN 50173, IEC 61156-7, EN 50288-9-1. Ideally suited for the transmission of analog and digital, data, audio and video signal transmission, 10 Gbit Ethernet, POE and POE+. The shield structure consists of individually shielded pairs with a tinned copper braid, which ensures excellent shielding and electrical values.
| Features | |
|---|---|
| Product colour | Yellow |
| Country of origin | China |
| Conductor material | Copper |
| Frequency | 1500 MHz |
| AWG wire size | 22/1 |
| Plug and Play | Yes |
| Cable standard | Cat7a |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | No |
| Connector 2 | No |
| Cabling technology | 10GBase-T |
| Jacket material | Low smoke zero halogen (LSZH) |
| Conductor type | Solid |
| Cable length | 500 m |
| Ethernet interface type | 10 Gigabit Ethernet |
| Cable shape | Round |
| Connector 2 gender | No |
| Connector 1 gender | No |
| Certification | CPR class B2ca |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 75 °C |
| Operating temperature (T-T) | -20 - 50 °C |
| Certificates | |
| Certification | CPR class B2ca |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
|---|---|
| Package volume | 0 cm³ |
| Package width | 0 mm |
| Package depth | 0 mm |
| Package type | Box |
| Package weight | 0 g |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Product colour | Yellow |
| Plug and Play | Yes |
| Cable standard | Cat7a |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | No |
| Connector 2 | No |
| Cabling technology | 10GBase-T |
| Jacket material | Low smoke zero halogen (LSZH) |
| Conductor type | Solid |
| Cable length | 500 m |
| Country of origin | China |
| Other features | |
| Package type | Box |
| Logistics data | |
| UK Trade Tariff code | 85444920 |
