Digitus CAT 8.2 S/FTP data cable - installation cable, 100 m, simplex, Dca
€225.58
€189.56
CAT 8.2 S-FTP installation cable,2000 MHz Dca, 100 m, ring, AWG 22/1, simplex, green
Availability:
In stock
Only 25 left
SKU
DK-1843-VH-1
- Physical properties:
- Conductor: Bare copper wire, AWG 22/1
- Insulation: SFS-PE (foamed polyethylene jacket)
- Total number of insulated conductors: 8, twisted into 4 pairs
- Color code: Blue-white, orange-white, green-white, brown-white
- Shielding of the individual pairs: Aluminum-laminated polyester film, covers 100%
- Overall shielding: Tinned copper braiding
- Outer sheath: Dca-s2,d1,a1 according to EN 50575
- Outer sheath thickness (nominal): 0.55 mm nominal
- Outer sheath color: Green
- Mechanical properties:
- Strain relief: 150N max.
- Dynamic bending radius: 8x AD mm min.
- Static bending radius: 4x AD mm min.
- Transport and storage temperature range: -20 °C to +75 °C
- Operating temperature range: -20 °C to +60 °C
- Installation temperature range: 0 °C to +50 °C
- Outer diameter simplex (nominal): 7.9 mm nominal (Dca)
- Weight (kg/km): 65 kg/km
- Electrical properties:
- Impedance: 100±15Ohm @ 1 - 2000MHz
- Capacitance: 99 pF/30m nominal @ 1 KHz
- Capacitance unbalance (pair-earth): 99pF/30m max. @ 1 KHz
- Insulation resistance: 5 GOhm x km min.
- DC resistance: 2.4Ohm/30m max. (4% max. unbalanced resistance)
- Loop resistance: 5.6 Ohm/24m max. (3% max. unbalanced resistance)
- Operating voltage: 72 Vdc max.
- Coupling attenuation: CA-Type 1
- Phase delay: 171 nS/30 m max.
- Time delay: 13.5 nS/130 m max.
- Separation class: "d" according to EN 50174-2
- NVP: 74%
| Cable length | 100 m |
|---|---|
| Connector 2 | No |
| Connector 1 | No |
| Cable shielding | S/FTP (S-STP) |
| SKU | DK-1843-VH-1 |
| EAN | 4016032476207 |
| Manufacturer | Digitus |
| Availability | In Stock |
Write Your Own Review
Future-oriented standards and high-end quality for your network
- 40 GBit Ethernet
- 2000 MHz transmission frequency
- 4PPoE Power over Ethernet support
- BauPVO class Dca
The DIGITUS® Professional CAT 8.2 S/FTP installation cable is characterized by the following cable construction 4x2x AWG22/1 and achieves a transmission frequency of up to 2000 MHz. The halogen-free cable sheath complies with IEC 60332-3-24, FRNC-C, LSZH-3 and CPR Euroclass Dca standards. The cable is suitable for building cabling in secondary and tertiary applications. Complies with the following standards: ISO/IEC 11801, DIN EN 50173, DIN EN 50288-12-1.
- 40 GBit Ethernet
- 2000 MHz transmission frequency
- 4PPoE Power over Ethernet support
- BauPVO class Dca
The DIGITUS® Professional CAT 8.2 S/FTP installation cable is characterized by the following cable construction 4x2x AWG22/1 and achieves a transmission frequency of up to 2000 MHz. The halogen-free cable sheath complies with IEC 60332-3-24, FRNC-C, LSZH-3 and CPR Euroclass Dca standards. The cable is suitable for building cabling in secondary and tertiary applications. Complies with the following standards: ISO/IEC 11801, DIN EN 50173, DIN EN 50288-12-1.
| Features | |
|---|---|
| Product colour | Green |
| Country of origin | China |
| Connector shielding | Yes |
| Connector shield material | Aluminium |
| Conductor material | Copper |
| AWG wire size | 22/1 |
| Cable standard | Cat8.2 |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | No |
| Connector 2 | No |
| Jacket material | Low smoke zero halogen (LSZH) |
| Conductor type | Solid |
| Cable length | 100 m |
| Ethernet interface type | 40 Gigabit Ethernet |
| Cable shape | Round |
| Connector 2 gender | No |
| Connector 1 gender | No |
| Certification | CPR class Dca |
| Harmonized System (HS) code | 84733080 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 75 °C |
| Operating temperature (T-T) | -20 - 60 °C |
| Certificates | |
| Certification | CPR class Dca |
| Packaging content | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package volume | 14297 cm³ |
| Package width | 290 mm |
| Package depth | 290 mm |
| Package weight | 6 kg |
| Quantity per pack | 1 pc(s) |
| Technical details | |
| Product colour | Green |
| Cable standard | Cat8.2 |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | No |
| Connector 2 | No |
| Jacket material | Low smoke zero halogen (LSZH) |
| Conductor type | Solid |
| Cable length | 100 m |
| Country of origin | China |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| UK Trade Tariff code | 85444920 |
