Digitus Gigabit EthernetPoE Injector, Industrial
€110.82
€93.13
Industrial Gigabit PoE Injector FullIEEE802.3af,at,bt Compliant, up to 85 W
Availability:
In stock
Only 5 left
SKU
DN-651141
- No. of Ports: 1
- Pass Through Data Rates: 10/100/1000Mbps
- Power over Ethernet Output: Pin Assignment and Polarity: Alternative A: V+ (RJ45 Pin3,6), V- (RJ45 Pin 1,2), Alternative B : V+ (RJ45 Pin4,5), V- (RJ45 Pin 7,8), User Port Power: 84W max
- Input Power Requirements: DC Input Voltage: 45 to 56 VDC
- Indicators: System Indicator: DC Power
- User Indicator: Channel Power
- Connectors: Shielded RJ-45, EIA 568A and 568B
- Regulatory Compliance: IEEE802.3af, IEEE802.3at, IEEE802.3bt type3, IEEE802.3bt type4
- Full IEEE802.3af, IEEE802.3at, IEEE802.3bt Compliant
- Up to 85W of Power on 4-pairs
- Auto-detect of IEEE802.3af, IEEE802.3at, IEEE802.3bt PD
- Supports 10/100/1000Base-T applications
- LED indicators power input and PoE output indication
- Distance up to 100 meters
- DC Input 45~56V
- DIN-Rail installation
- Wide operating temperature: -40 ~ +75°C
- Environmental Conditions:Operating Ambient Temperature: -40 ~ +75°C
- Operating Humidity: 90%, Non-condensing
- Storage Temperature:-40 to 75°C
- Storage Humidity: 95%, Non-condensing
- Dimension (W x D x H): 103 x 78 x 32 mm
- Weight: 295g
| SKU | DN-651141 |
|---|---|
| EAN | 4016032486541 |
| Manufacturer | Digitus |
| Availability | In Stock |
Write Your Own Review
Industrial Gigabit PoE Injector, full IEEE802.3af, at, bt Compliant, up to 85 W
- Full IEEE802.3af, IEEE802.3at, IEEE802.3bt Compliant
- Up to 85W of Power on 4-pairs
- Auto-detect of IEEE802.3af, IEEE802.3at, IEEE802.3bt PD
- Supports 10/100/1000Base-T applications
- LED indicators power input and PoE output indication
- Distance up to 100 meters
- DC Input 45~56V
- DIN-Rail installation
- Wide operating temperature: -40 ~ +75℃
The DN-651141 is a single port Mid-spans offer a compact and cost effective, fully IEEE802.3bt compliant solution for remote powering of wireless LAN (WAN) access points, IP Security cameras, VoIP telephone and other low port density installations. The DN-651141 PoE Mid-spans eliminate the need for external power supply and its associated AC/DC power cabling, providing a compact, affordable, safe and reliable power solution over existing Ethernet infrastructure.
- Full IEEE802.3af, IEEE802.3at, IEEE802.3bt Compliant
- Up to 85W of Power on 4-pairs
- Auto-detect of IEEE802.3af, IEEE802.3at, IEEE802.3bt PD
- Supports 10/100/1000Base-T applications
- LED indicators power input and PoE output indication
- Distance up to 100 meters
- DC Input 45~56V
- DIN-Rail installation
- Wide operating temperature: -40 ~ +75℃
The DN-651141 is a single port Mid-spans offer a compact and cost effective, fully IEEE802.3bt compliant solution for remote powering of wireless LAN (WAN) access points, IP Security cameras, VoIP telephone and other low port density installations. The DN-651141 PoE Mid-spans eliminate the need for external power supply and its associated AC/DC power cabling, providing a compact, affordable, safe and reliable power solution over existing Ethernet infrastructure.
| Features | |
|---|---|
| LED indicators | Yes |
| Plug and Play | Yes |
| Power over Ethernet (PoE) | No |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Product colour | Black |
| Cabling technology | 10/100/1000Base-T(X) |
| Country of origin | China |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| Operational conditions | |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Width | 103 mm |
| Weight | 295 g |
| Height | 32 mm |
| Depth | 78 mm |
| Package width | 188 mm |
| Package depth | 95 mm |
| Package height | 165 mm |
| Package weight | 331.389 g |
| Package volume | 4286.4 cm³ |
| Packaging content | |
| Quick installation guide | Yes |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package width | 188 mm |
| Package depth | 95 mm |
| Package height | 165 mm |
| Package weight | 331.389 g |
| Package volume | 4286.4 cm³ |
| Network | |
|---|---|
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Cabling technology | 10/100/1000Base-T(X) |
| Power over Ethernet (PoE) | No |
| Performance | |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Cabling technology | 10/100/1000Base-T(X) |
| Design | |
| LED indicators | Yes |
| Country of origin | China |
| Plug and Play | Yes |
| Product colour | Black |
| Power | |
| Power over Ethernet (PoE) | No |
| Output power | 85 W |
| Input voltage | 45 - 56 V |
| Technical details | |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Colour | |
| Product colour | Black |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Country of origin | China |
| UK Trade Tariff code | 85176200 |
You may also be interested in
| Product |
Bestseller
Digitus Gigabit EthernetPoE Injector,...
€110.82
€93.13
|
Recommended
Digitus Industrial Gigabit PoE++ Split...
€147.21
€123.71
|
LevelOne Fast Ethernet High Power PoE...
€144.12
€121.11
|
Hot Product
PLANET POE-171S network splitter Power...
€96.93
€81.45
|
PLANET POE-172S network splitter Power...
