LevelOne 24V DC Industrial Power Supply, 480W, DIN-Rail,-20 ~ +70 ℃
€291.67
€245.10
24V DC Industrial Power Supply, 480W, DIN-Rail,-20 ~ +70 ℃
Availability:
In stock
Only 9 left
SKU
POW-2462
- Universal AC Input at Full Range
- Short Circuit, Overload / Over Voltage Protection
- Fanless Design Supports
- DIN-rail installation
- 102% Full Load
- Burn-in Test DC OK Relay Contact
| Total power | 480 W |
|---|---|
| SKU | POW-2462 |
| EAN | 4015867236581 |
| Manufacturer | LevelOne |
| Availability | In Stock |
| PDF URLs |
View PDF |
Write Your Own Review
The POW-2462 should be able to accept a wide range of input voltages, typically from 90V AC to 264V AC, allowing it to operate in various industrial environments.
DIN-rail Mounting to fit standard DIN-rail mounting systems commonly used in industrial cabinets, allowing for easy installation and space-saving.
It's essential for the power supply to have high energy efficiency, reducing power losses and operating costs while minimizing heat generation.
DIN-rail Mounting to fit standard DIN-rail mounting systems commonly used in industrial cabinets, allowing for easy installation and space-saving.
It's essential for the power supply to have high energy efficiency, reducing power losses and operating costs while minimizing heat generation.
| Design | |
|---|---|
| Safety | EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) |
| Product colour | Blue, Silver |
| Country of origin | China |
| Power | |
| Total power | 480 W |
| AC input voltage | 90 - 264 V |
| Voltage tolerance | 1% |
| AC input frequency | 47 - 63 Hz |
| Input current | 4.8 A |
| Power protection features | Overload, Over voltage, Short circuit |
| Hold time | 16 ms |
| Performance | |
| Safety | EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) |
| Mean time between failures (MTBF) | 1041600 h |
| Country of origin | China |
| Harmonized System (HS) code | 8504403090 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
| Weight & dimensions | |
|---|---|
| Width | 85.5 mm |
| Depth | 128.5 mm |
| Height | 125.2 mm |
| Weight | 1.42 kg |
| Packaging data | |
| Package depth | 171 mm |
| Package width | 122 mm |
| Package height | 150 mm |
| Package type | Box |
| Package weight | 1.5 kg |
| Certificates | |
| Safety | EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) |
| Logistics data | |
| Master (outer) cases per pallet | 20 pc(s) |
| Master (outer) case width | 266 mm |
| Master (outer) case length | 361 mm |
| Master (outer) case height | 323 mm |
| Master (outer) case gross weight | 11.4 kg |
| Harmonized System (HS) code | 8504403090 |
| Other features | |
| Voltage tolerance | 1% |
| Output voltage note | 24 |
| Harmonized System (HS) code | 8504403090 |
