LevelOne Industrial Gigabit PoE Injector, 36W, 802.3at/af PoE
€176.17
€148.04
10/100/1000 Mbps RJ-45, 48V~56V VDC, 370 g
Availability:
In stock
Only 24 left
SKU
IGP-0101
| SKU | IGP-0101 |
|---|---|
| EAN | 4015867196045 |
| Manufacturer | LevelOne |
| Availability | In Stock |
| PDF URLs |
View PDF |
Write Your Own Review
The LevelOne IGP-0101 is rugged designed 30 Watts, high power Single port industrial POE Injector is equipped with our high efficiency ColdDesign technology to provide 30 Watts power to your security equipment. The ColdDesign technology will not only power up your PD device, also reduce the excessive heat problem to a minimum. It accepts the input voltage from 48~56 VDC to deliver 30Watts power to meet IEEE802.3af/at standard. It is being rigorously tested for your Security, Transportation and Telco application.
Key Features
- PoE ports can support the IEEE 802.3at standard and power up 30W devices
- 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
- 40°C to 75°C operating temperature range
- Provides DIN-rail, wall or desktop mounting
- IP30 metal case
- Redundant power inputs with Terminal Block
Key Features
- PoE ports can support the IEEE 802.3at standard and power up 30W devices
- 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
- 40°C to 75°C operating temperature range
- Provides DIN-rail, wall or desktop mounting
- IP30 metal case
- Redundant power inputs with Terminal Block
| Network | |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Duplex system | Full |
| Power over Ethernet (PoE) | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Power over Ethernet (PoE) voltage | 56 V |
| Features | |
| Wall mountable | Yes |
| Product colour | Black |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Safety | EN60950-1Ç EN55022/24, EN50155, EN55011, EN50121-3-2 EN60068-2-7, EN60068-2-27, EN60068-2-32 |
| LED indicators | PoE, Power |
| Certification | CE, FCC, RoHS, VCCI |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
| Output power | 36 W |
| Power over Ethernet (PoE) voltage | 56 V |
| Technical details | |
| Package width | 165 mm |
| Package height | 215 mm |
| Safety | EN60950-1Ç EN55022/24, EN50155, EN55011, EN50121-3-2 EN60068-2-7, EN60068-2-27, EN60068-2-32 |
| Power over Ethernet (PoE) | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Harmonized System (HS) code | 85044095 |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 85 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
|---|---|
| Package weight | 370 g |
| Package depth | 65 mm |
| Package width | 165 mm |
| Package height | 215 mm |
| Weight | 140 g |
| Width | 81.5 mm |
| Depth | 32 mm |
| Height | 103.5 mm |
| Packaging data | |
| Package weight | 370 g |
| Package depth | 65 mm |
| Package width | 165 mm |
| Package height | 215 mm |
| Packaging content | |
| Manual | Yes |
| Certificates | |
| Certification | CE, FCC, RoHS, VCCI |
| Indication | |
| LED indicators | PoE, Power |
| Logistics data | |
| Harmonized System (HS) code | 85044095 |
