Lindy 0.3m RJ45 S/FTP LSZH Cable, Green

€4.30 €3.61
0.3m RJ45 S/FTP LSZH Network Cable, Green
Availability:
In stock
Only 48 left
SKU
47645
  • Twisted Pair Patch Cable with RJ45 connectors
  • Connector: Cat.6A / Cable: Cat.7 S/FTP (600Mhz)
  • Integrated snagless connector for latch protection
  • Gold plated pins for better conductivity and elimination of signal loss
More Information
Cable length 0.3 m
Connector 2 RJ-45
Connector 1 RJ-45
Cable shielding S/FTP (S-STP)
SKU 47645
EAN 4002888476454
Manufacturer Lindy
Availability In Stock
Write Your Own Review
You're reviewing:Lindy 0.3m RJ45 S/FTP LSZH Cable, Green
Cat.7 S/FTP LSZH network cable with Cat.6A connectors supports bandwidth up to 600MHz and features a snagless design with gold plated contacts for ethernet standards up to 10 GBase-T.
The Cat.7 cable material for operating frequencies up to 600MHz with taotal braided shielding and foil single-wire shielding (S/FTP) was developed for use in data centres, server rooms, rack mounting of network and control cabinets etc. for networks up to 10GBaseT. These cables are manufactured and tested according to the ISO/IEC 11801 specification. The cables are packaged individually in a polybag.
The gold-plated contacts ensure reliable, corrosion-free connections over extensive periods of time. A robust snagless strain relief design prevents damage to the connector latch during installation and removal.
This product uses Cat.7 cable material. The Cat.7 standard originally defined the GG45 connectors, which were intended as a further development of RJ45, but were not able to establish themselves on the market. In the meantime, the RJ45 connector developed to easily meet the requirements of Cat.7, but has never been defined for Cat.7. Therefore the imprint on the cable reads as follows: Cat.6A S/FTP patch cords with 600MHz raw cable .
Available lengths: 0.3m, 0.5m, 1m, 1.5m, 2m, 3m, 5m, 7.5m, 10m, 15m, 20m, 30m.
Available colours: Black, Blue, Grey, Red, White.
Technical details
Product colourGreen
Cable standardCat7
Cable shieldingS/FTP (S-STP)
Connector 1RJ-45
Connector 2RJ-45
Connector contacts platingNickel
Jacket materialLow smoke zero halogen (LSZH)
Cable length0.3 m
Certificates
CertificationRoHS, REACH, UL, California Proposition 65
Features
Product colourGreen
Connector shieldingYes
Connector shield materialCopper alloy
Conductor materialCopper
Frequency600 MHz
AWG wire size26
Cable standardCat7
Cable shieldingS/FTP (S-STP)
Connector 1RJ-45
Connector 2RJ-45
Connector contacts platingNickel
Jacket materialLow smoke zero halogen (LSZH)
CertificationRoHS, REACH, UL, California Proposition 65
Cable length0.3 m
Connector 2 genderMale
Connector 1 genderMale
Connector housing materialPolycarbonate (PC)
Bend radius (min)7.8 cm
Connector 2 form factorStraight
Connector 1 form factorStraight
Operational conditions
Storage temperature (T-T)-20 - 75 °C
Operating temperature (T-T)-10 - 60 °C
Weight & dimensions
Outer diameter6.5 mm
Connector 2 dimensions (WxDxH)11.6 x 22.8 x 8.3 mm
Connector 1 dimensions (WxDxH)11.6 x 22.8 x 8.3 mm
Packaging data
Package typePolybag
Other features
Package typePolybag
